     TechCut 4TM Low Speed Saw


Excellent for low speed, precision applications

A precision low speed saw excellent for cutting smaller, delicate samples that cannot tolerate excessive friction and heat caused by high speed sectioning. The gravity-fed cutting system uses adjustable weights to apply or counterbalance downward force to the sample during sectioning. Cutting fluid is drawn from the reservoir by the rotating blade and applied to the sample. With a 3 to 6 inch blade range, samples up to 2 inches thick can be sectioned.

Features:

  • Gravity-fed cutting system
  • 3-6 inch (75-150 mm) diameter blade range, 1/2-inch (12.7 mm) arbor
  • Variable speed LED display: 10-500 RPM (10 RPM increments)
  • Cutting capacity: 2-inch (51 mm) diameter
  • Micrometer sample indexing, 1-micron resolution, 2-inch range
  • Spring-loaded dressing stick attachment allows dressing while sectioning
  • Automatic optical shut-off sensor with adjustable stop to control depth of cut
  • Precision machined aluminum and stainless steel construction offers maximum corrosion-resistance and durability
  • 1/17 HP (45W) geared DC motor
  • Sliding weights provide variable sample loading: 0-300 grams
  • Removable coolant reservoir
  • Touch pad switches control all functions
  • Removable splash shield (not shown)
  • Removable catch screen prevents sectioned pieces from falling into reservoir
  • Dimensions: 11" W x 17" D x 14" H (279 x 432 x 356 mm)
  • Weight: 40 lb. (18 kg)
  • Two (2) year warranty - parts and labor
  • Designed & manufactured in the USA

Item No. Description
5-5000

TechCut 4™ Low Speed Saw, 115 V. Includes: 60-20075 Diamond Wafering Blade, #5-5005 Mount Holder, #5-5010 V-Block Fixture, #5-5020 Single Saddle Clamp, #60-20110 Cutting Fluid, 32 oz. and #60-20105 Dressing Stick
5-5000-230

TechCut 4™ Low Speed Saw, 230V 50/60Hz 1 Phase.
Accessories
5-5005 Mount Holder, 1.25"/32mm capacity [A]
5-5010 V-Block Fixture, 1" Capacity [B]
5-5015 Bone Fixture[C]
5-5020 Single Saddle Clamp[D]
5-5025 Glass Slide/Thin Section Fixture, Vacuum Type[E]
5-5030 Irregular Shaped Sample Fixture[F]
5-5035 Dual Saddle Clamp[G]
5-5040 Swivel Attachment (to adapt other fixtures for specific angle cutting)[H]
5-5045 2½" Flange Set


    Diamond Band Saw

Versatile, affordable sectioning machine, excellent for coarse or non-linear cutting of materials such as printed circuit boards, electronic packages, substrates, polymers and other non-metallics. Coolant is drawn from the reservoir by the blade and applied to the sample. Durable injection molded plastic construction prevents corrosion.

Features:

  • 1/3 HP (250 W) motor, 2850 RPM
  • Coolant tank, 1-gallon (3.8 L) capacity
  • Durable plastic injection body prevents corrosion
  • Large cutting platform 12" W x 11" D (305 x 280 mm) accommodates oversized samples
  • Allows tight-radius sectioning for sample extraction from large pieces
  • Single knob, semiautomatic blade tension adjustment
  • Dimensions: 11" W x 15" D x 18" H (279 x 381 x 457 mm)
  • Weight: 20 lb. (9 kg)
  • One (1) year warranty - parts and labor
Item No. Description
70-1500

Diamond Band Saw Includes:
(1) Band Saw Blade and Cutting Fluid 115V 60Hz 1 Phase
Accessories
70-1505

Diamond Plated Band Saw Blades with Teflon?Replacement Guides (Pk/2)


    Trim Saw


Excellent for rapid sectioning of printed circuit boards, ceramic substrates, electronic packages and other materials. Cutting fluid is drawn from the reservoir by the rotating blade and applied to the sample. Durable molded plastic construction prevents corrosion.

Features:

  • 1/8 HP (90W) motor, variable speed: 500-3000 RPM
  • 4-6 inch (100-150 mm) blade range, 1/2-inch (12.7 mm) arbor
  • Durable plastic injection molded body prevents corrosion
  • Plexiglass cover (removable) for safety and splash protection
  • Large cutting platform: 6? W x 12? D (165 x 318 mm)
  • Adjustable table rip fence for repeatable, guided sectioning
  • Coolant reservoir, 1/2-gallon (1.9 L) capacity
  • Dimensions: 16" W x 16" D x 14" H (406 x 406 x 356 mm)
  • Weight: 25 lb. (11.3 kg)
  • One (1) year warranty - parts and labor
Item No. Description
70-30010

Variable Speed Trim Saw Includes:
#65-10030 Dia-Cut Diamond Wafering Blade, and #80-10155 Cutting Fluid, 32 oz. 115V 60Hz 1 Phase


    TechCut10TM Abrasive Cut-Off Saw


Quality for a wide variety of cut-off applications

A powerful bench-top abrasive cut-off saw for sectioning various types and sizes of metallographic samples. The PowerCut10™ uses blades ranging from 8 to 10 inches in diameter, allowing materials up to 3 inches thick to be sectioned. A side port accommodates longer samples such as bar stock.

Features:

  • 10-inch diameter blade capacity
  • Blades with either 1¼" or 32mm arbor hole can be used
  • Powerful 3.5HP (2500 W) motor, 3450 RPM
  • Cutting capacity: Up to 3-inch bar stock
  • Bench top mountable
  • One (1) Stainless Steel Quick-Slide vise with 3-inch capacity
  • Two (2) T-Slot tables allow front-to-back and side-to-side vise/clamp positioning
  • Optional Vertical Adjusting clamp available for odd-shaped samples
  • Large, fog-resistant, shatterproof viewing window
  • Illuminated cutting chamber
  • Recirculating coolant system with cleaning hose, 7-gallon capacity
  • Stainless Steel coolant tank with removable stainless steel settling pan
  • Lubrication fittings on motor hinge allow smooth blade feed
  • Corrosion and impact resistant cover
  • Cast aluminum base
  • Rubber sealed side-port for cutting long bar stock
  • Electronic brake stops blade for operator safety
  • Safety auto-shutoff switch for cover
  • Emergency shut-off switch
  • Dimensions: 24" W x 23" D x 17" H (610 x 584 x 431 mm)
  • Weight: 161 lb. (73 kg)
  • Two (2) year warranty - parts and labor

zWww Traveldealspackage K Square Szh Q Singapore Tourism Board Travel Deals Package ALLIED金相制样 研磨抛光设备 切割类-展芯设备代理y Travel Deals PackagehWww Traveldealspackage K Square Szh Q Singapore Tourism Board Travel Deals Package ALLIED金相制样 研磨抛光设备 切割类-展芯设备代理u s Travel Deals Package
Item No. Description
30-4000

PowerCut10™ Abrasive Cut-Off Saw Includes: #5-4005 Vise, Quick-Slide Stainless Steel, with 3" Capacity, #80-10155 Cutting Fluid, 32 oz. and #80-ASSORT assorted 10" Cut-Off blades 230V 50/60Hz 3 Phase
